I. Application Scope:

This equipment is suitable for hydraulic testing within the range of 0-280 MPa. It can meet the factory inspection requirements for products such as drilling blowout preventers, X-mas trees and wellhead assemblies, choke and kill manifolds, as well as the functional testing of the aforementioned products.

This model of hydraulic test bench is applicable for pressure tightness testing of various pressure vessels, including but not limited to petroleum engineering pipes, blowout preventers, valves, gas wellhead assemblies, manifolds, downhole tools, as well as those used in the aviation industry, scientific research institutions, and other sectors.

The equipment complies with the following standards and requirements:

II. Test Standards:

• SY/T5053.1～2000 Blowout Preventers and Control Devices - Blowout Preventers

• SY/T5127～2002 Specification for Wellhead Equipment and Christmas Trees

• API Spec 16A / ISO 13533 Specification for Drill-Through Equipment

• API Spec 16C Choke and Kill Systems

• API Spec 6A / ISO 10423 Wellhead and Christmas Tree Equipment

• Public Security Industry Standards and departmental requirements for security engineering management

Data Acquisition Software:

III. Equipment Features:

1. The equipment pressure is adjustable and controllable.

2. It can be configured with video surveillance for remote monitoring.

3. All pressure-bearing components utilize standard parts from internationally renowned brands. With no welded connections, they are easy to disassemble, feature high safety factors, long service life, and are convenient for maintenance.

IV. Technical Specifications

1. Driving Air Pressure Range: 0.1-0.69 MPa; the output pressure is proportional to the driving air pressure.

2. Air Consumption: 1.6 Nm³/min

3. Pressure Testing Range: 0-280 MPa. The corresponding pressure can be selected based on actual customer requirements.

4. Working Medium: Water/Hydraulic Oil.

5. Computerized data acquisition and control systems can be configured according to customer requirements.

V. Model Selection

Portable Pneumatic Pressure Test Pump System

The system is equipped with a circular chart recorder for real-time recording of pressure test data and weighs less than 30kg. It can achieve a maximum hydraulic pressure of up to 280MPa, meeting the on-site pressure testing requirements for blowout preventers, Christmas trees, and wellhead assemblies.
